Product Details
GENERAL INFORMATION
Order CodeLT-100WHBL-5050
MakeLightronix Technology
Country of OriginINDIA
Lighting Source & TypeSMD 5050 LED
Number of LED20
OPTICAL PARAMETERS
Led Beam Angle120 degree
CRI (Color Rendering Index)>80
LED Life Span>60000 Hours
ColorWhite/Warm White/Cool White (As Per Order)
Color Temperature2700-6500K(As Per Order)
Led Voltage/Current6.2V/750mA
LED MakeSeoul/Bridge lux/Cree/Nichia/Osram (As per Requirement)
Optical LensNA
Luminous Efficiency170 Lm/W
Total Lumens17000(±5%)
Optical Efficiency>93%
Thermal Efficiency>90%
ELECTRICAL PARAMETERS
Wide Input Voltage Range90-310VAC(With Auto Cutoff)
Operating Frequency50/60 HZ
Power Consumption100 Watt
Power Factor>0.95
THD<10%
Driver Surge Protection4-6KV
External Surge Protection10KV (As per Requirement)
Control GearConstant current LED Driver
Operating Temperature-40 to 75°C
Max. Case Temperature+90°C
Working Humidity20~95% RH non-condensing
Driver thermal ProtectionYes
Electrical Efficiency>90%
Supply PhaseSingle Phase Supply
Over voltage Protection440VAC Protection
Under voltage Protection90VAC
Auto cutoff VoltageLower Side<90VAC & Higher Side>310VAC
PCB INFORMATION
PCB Thickness1.6mm(±5% Tolerance)
PCB MaterialPure Aluminum-Copper
Copper Layer ThicknessStandard 0.35 Micron
Copper Conductivity>1 Watt
PCB Size230X230 mm
MECHANICAL PARAMETERS
Housing MaterialAluminum Pressure Die Casting
Housing Color TypeMetal Powder Coated
Housing ShapeRound
Total Luminaries Weight3.910 Kg
Luminaries Size Diameter - 380 mm
Height – 122 mm
Mounting DeviceBracket
Mounting Style Ceiling/Roof/Hanging
Glass Type4mm Toughen Glass
Glass Size Diameter - 242 mm
Cable Entry OptionPG7 Cable Gland with Rubber Washer
Screw TypeStainless Steel Screw
Gasket TypeSilicone Rubber Gasket
IP RatingIP65/IP66
Impact RatingIK08/IK10
Marking TypeLaser Marking/Engraving
Specifications
| Wattage | 100 W |
| Packing Case Lot | 08 nos |
| Minimum Order Quantity | 02 PCS |
| Luminaire light beam spread | 120 DEGREE |
| Total weight | 2.2 KG |
| Input voltage | 230VAC |
| Heat Sin ( Diameter x Length) (inmm) | 230x180 |
| Surge protection | 6KV + 10KV |
| Led Beam Angle | 120 Degree |
| CRI (Color Rendering Index) | >80 |
| LED Life Span | >60000 Hours |
| Color | White/Warm White/Cool White (As Per Order) |
| Color Temperature | 2700-6500K(As Per Order) |
| Led Voltage/Current | 6.2V/750mA |
| LED Make | Bridge lux/Osram (As per Requirement) |
| Optical Lens | NA |
| Luminous Efficiency | 170 Lm/W |
| Total Lumens | 17000(±5%) |
| Optical Efficiency | >93% |
| Thermal Efficiency | >90% |
| Wide Input Voltage Range | 90-310VAC(With Auto Cutoff) |
| Operating Frequency | 50/60HZ |
| Power Consumption | 100 Watt |
| Power Factor | >0.95 |
| THD | <10% |
| Driver Surge Protection | 4-6KV |
| External Surge Protection | 10KV (As per Requirement) |
| Control Gear | Constant current LED Driver |
