| Business Type | Manufacturer, Exporter, Supplier |
| Lifetime | 50000 Hours |
| LED Lumen | 140 |
| SPD | 10KV |
| Click to view more | |
Product Details
Beam Angle
120
Driver
6KV IP66 Isolated Driver
6KV driver
Isolated IP66 Driver
Material alluminium body
Aluminum Casting
Power Factor
>0.95
Power Requirement
50W
CRI
80
Protection rating
IP66
Power Consumption
50W
Light Source
LED
Body Color
Grey
Housing Material
Aluminum Casting
Power Supply
230VAC
Condition
NEW
Feature
Suitable For Indoor Or Outdoor, Stable Performance, Low Consumption, Bright And Shining
Color
White / Warm White / Cool White
Weight
1-2kg
Application
Shop, Market, Malls, Garden, High Mast,SPor
Material
Aluminum Casting
Country of Origin
India
Wattage
50W
Frequency
50Hz
Voltage
230VAC
Power
50W
Product Code
LT-50WFL-ORION
Specifications
| OPTICAL PARAMETERS | |
| Led Beam Angle | 120 Degree |
| CRI (Color Rendering Index) | >80 |
| LED Life Span | >60000 Hours |
| Color | White/Warm White/Cool White (As Per Order) |
| Color Temperature | 2700-6500K(As Per Order) |
| Led Voltage/Current | 6.2V/150mA |
| LED Make | Seoul/Bridge lux/Cree/Nichia/Osram (As per Requirement) |
| Optical Lens | NA |
| Luminous Efficiency | 140 Lm/W |
| Total Lumens | 7000(±5%) |
| Optical Efficiency | >93% |
| Thermal Efficiency | >90% |
| ELECTRICAL PARAMETERS | |
| Wide Input Voltage Range | 90-310VAC(With Auto Cutoff) |
| Operating Frequency | 50/60HZ |
| Power Consumption | 50 Watt |
| Power Factor | >0.95 |
| THD | 90.00% |
| Supply Phase | Single Phase Supply |
| Over voltage Protection | 440VAC Protection |
| Under voltage Protection | 90VAC |
| Auto cutoff Voltage | Lower Side310VAC |
| PCB INFORMATION | |
| PCB Thickness | 1.6mm(±5% Tolerance) |
| PCB Material | Pure Aluminum-Copper |
| Copper Layer Thickness | Standard 0.35 Micron |
| Copper Conductivity | >1 Watt |
| PCB Size | 135X93 mm |
| MECHANICAL PARAMETERS | |
| Housing Material | Aluminum Pressure Die Casting |
| Housing Color Type | Metal Powder Coated |
| Housing Shape | Rectangle |
| Total Luminaries Weight | 1.910 Kg |
| Luminaries Size | 182 × 254 × 120 mm3 |
| Mounting Device | Bracket |
| Mounting Style | Wall/Pole/Ceiling/Roof/Hanging |
| Glass Type | 4mm Toughen Glass |
| Glass Size | 169x224 mm² |
| Cable Entry Option | PG7 Cable Gland with Rubber Washer |
| Screw Type | Stainless Steel Screw |
| Gasket Type | Silicone Rubber Gasket |
| IP Rating | IP65/IP66 |
| Impact Rating | IK08/IK10 |
| Marking Type | Laser Marking/Engraving |
